TRIPLE ir FLAME DETECTORS

fgd - IR3 Flame deteCTORS

FlameSpec IR3 Flame Detector Range



FlameSpec-IR3 is the next generation of Triple IR Flame Detector, it is being introduced to further enhance the protection and safety for those high risk and high value industries.​The FlameSpec-IR3 will detect fires and explosions extremely fast, thus allowing preventative action to be initiated even more rapidly and minimizing the consequences!​ It provides ultra-fast response, high performance and reliable detection of all types of hydrocarbon fires (visible and non-visible). The detector addresses slow growing fires as well as fast eruption of fire using improved Triple IR (IR3) technology. It operates in all weather and light conditions with highest immunity to false alarms. The unmatched detection times and distances are:


  • Detection within 40 milliseconds of fireballs or explosions
  • 1.2seconds – for 1ft² (0.1m²) n-heptane pan fire at up to 50 ft. (15m)
  • <4.1seconds– for 1ft² (0.1m²) n-heptane pan fire at up to 230 ft. (70m)


Add to that, the integral event recording, on top of the proven superior capabilities of Triple IR (IR3) flame detection and you have a very powerful safety tool to protect your personnel, plant and process.


FlameSpec-IR3–HD has the addition of Integral HD quality video, with event recording, on top of the proven, superior capabilities of Triple IR (IR3) flame detection, providing a very powerful safety tool to protect personnel, plants, and processes. The detectors high-definition (HD) video output of the monitored area provides clear imaging of a fire event and of personnel at distances up to 100 ft (30m). This allows the rescue team to be aware of the exact situation before entering the hazardous area. The detector automatically records video of any fire event (1 minute pre- and up to 3 minutes post alarm initiation). These features, along with the built-in event logger, provide additional means to study the cause and development of fire events for “lessons learned” reviews.



Key Benefits:



FlameSpec-IR3 and IR3-HD:

  • Extreme sensitivity - up to 260ft (80m) for a 1ft² (0.1m²) n-heptane pan fire.


  • Ultra-fast detection mode - detection within 40 milliseconds for fireballs or explosions.


  • 1.3 second detection time - for 1ft² (0.1m²) n-heptane pan fire at up to 50 ft. (15m) distance.


  • Optimized option for aircraft hangars, helipads & truck loading racks available, see FLS-IR3 CO2L data sheet.


  • 5 selectable sensitivity levels.


  • Universal outputs, 3 and 4 wire, 4-20 mA sink / source, Fire, Auxiliary and Fault Relays. RS485 port using Modbus RTU.


  • Data/Event logger - alarms, faults and other relevant events are logged to non-volatile memory.


  • Built-in-Test (BIT) - Automatic and manual self-test of window cleanliness and the overall operation of the detector.


  • Window heater to avoid condensation and icing.


  • Tilt mounting bracket can be connected either above or below the detector.


  • High immunity to false alarm.


  • HART 7 models available - Easy configuration and diagnostic capability.


  • SIL 2 compliant models available - suitable for use as part of a SIL 2 compliant safety system.



FlameSpec-IR3–HD only:

  • HD video output with Automatic HD video recording of fire events.


  • Ethernet communication – in addition to the standard methods, such as Relays, 4-20mA and Modbus.




SPECIFICATIONS FlameSpec IR3 and IR3HD:

Detection time and distance:

40ms for fast fireburst or explosion

2.6s for 1 ft2 (0 .1m2) panfire at 0–100ft.(0–30m)

3.7sfor 1 ft2 (0 .1m2) panfire at 100–230ft.(30–70m)

Field of View: 90° Horizontal, 75° Vertical

Time Delay: 0-30 seconds

Built in Test: Automatic and Manual

Operating Voltage: 24 VDC nominal (18-32 VDC)

Current Consumption: Standby: 120mA, Operation: 180mA all systems in operation (including window heater)

Electrical Entries: 2x conduit entries 3/4" 14NPT or M25x1.5 Wiring 12-20 AWG (2.5–0.35mm2)

Relays: SPST volt-free contacts rated 2A at 30 VDC 3 relays: Alarm & Auxiliary – normally open; Fault – normally closed:

Analogue Output: 0-20mA (stepped) current output 3wire and 4wire (isolated) configurations (sinkand source), with HART overlay.

Local Indication: Tri-colour LED

Size: 140x90x90mm

Weight: Detector (StainlessSteel 316):3.0kg Tilt mount (Stainless Steel 316):1.5kg

Temperature Range: Operating: -55°C to +85°C Storage: -55°C to +85°C

Humidity: Up to 99% (RH), non-condensing

Ingress Protection: IP66 & 68 (2m, 24hr); NEMA 4X & 6P

Explosion proof:

ATEX: I I 2 G D Ex db IIC T5 G b or Ex db eb IIC T5 Gb and Ex tb IIIC T95°C Db -55°C<Ta<75°C Ex db IIC T4 Gb or Ex db eb IIC T4 Gb and Ex tb IIIC T105°C Db -55°C<Ta<85°C

IECEx ExdbIICT5Gb-50°C≤Ta≤75°CExdbIICT4Gb-50°C≤Ta≤85°C

FM & FMC Class I, Div. 1, Groups B, C & D; T4 Class I, Zone 1, AEx/Ex db IIC T4 Gb T4-50°C≤Ta≤85°CT5-50°C≤Ta≤75°C

PerformanceApproval:  ANSI FM 3260 EN 54 -10

Functional safety: SIL2, per I EC 61508

Marine Approval: DNVGL Certificate Number MED-B-00006AM


SPECIFICATIONS FlameSpec IR3HD only:

Current Consumption: Standby: 180mA, Operation: 250mA all systems in operation (including window heater)

Size: 200x130x130mm

Weight: Detector (StainlessSteel316):4.4kg Tilt mount (Stainless Steel316):2.4kg

HD Video: Allows clear imaging of fire and people at 100 ft. (30m) distance

Video recording: Alarm events 1-minute pre-event and up to 3 minutes post-event

System integration protocol: ONVIF (Open Network Video Interface Forum) Profile S

Digital Output (for video): IP network IEEE 802.3 10Base-t

Composite video output: NTSC or PAL

IR3 Flame Detector, IR3 Flame Detector with Video.

IR3 Flame Detector, IR3 Flame Detector with Video.

Downloads

  Click on the links below to download the Datasheets of the FLS IR3 Flame Detector Range,

go to our Resources page for application and selection information.

FLS-IR3-08 (pdf)

Download

FLS-IR3-HD-09 (pdf)

Download

FLS-FSIM-03 (pdf)

Download

Video

Performance Benefits of the FGD FlameSpec Product Range

Information on the perfomance gains FGD has made, and how they benefit the end user of the range of High Performance Flame Detectors

Triple IR Flame Detector

 FGD IR3 HD Utilised for Flame Detection in a Recycling Facility

Triple IR Flame Detector

Triple IR Flame Detector used on Class A Fires

FGD Flame Spec Model Range

Overview of the FGD Flame Spec Family of Advanced Flame Detectors
