uvir flame detectors

fgd UVIR Flame Detectors

FlameSpec-UV-IR Flame Detector Range.

FlameSpec-UV-IR model - UVIR flame detector providing ultra-fast response, high performance and reliable detection of a large variety of fires including hydrocarbon fires (visible and nonvisible), as well as Hydrogen fires. ​The detector addresses slow growing fires as well as fast eruptions of fire using improved UV IR technology. The detector operates in all weather and light conditions.​


FlameSpec-UV-IR-F model  - Same As FlameSpec-UV-IR but does not see hydroxyl and hydrogen  fires and IR sensor that operates at a wavelength of 4.0-5-0 μm​.



FlameSpec-UV-IR-HD and UV-IR-F-HD models - ​In  addition, the detector provides high-definition (HD) video output of  the monitored area with clear imaging of a fire event and of personnel at distances up to 100 ft (30m).This allows the rescue team to be aware of the exact situation before entering the hazardous area. The detector automatically records video of any fire event (1 minute pre- and up to 3 minutes post alarm initiation). These features, along with the built-in event logger, provide additional means to study the cause and development of fire events for “lessons learned” reviews.


Key Benefits:


FlameSpec-UVIR all models:

  • Hydrogen, Inorganic and Hydrocarbons flame detection.


  • Ultra-fast detection mode detection within 5 milliseconds for fireballs or explosions


  • High sensitivity - up to 100ft (30m) for a 1ft2 (0.1m2) n-heptane pan fire


  • High immunity to false alarm


  • Data/Event logger - alarms, faults and other relevant events are logged to non-volatile memory.


  • Ethernet communication – in addition to the standard methods, such as 4-20mA and Modbus.


  • Built-in-Test  (BIT) - Automatic and manual internal self-test of window cleanliness  and the overall operation of the detector (for both IR and UV channels).


  • Window heater to avoid condensation and icing.


  • Tilt mounting bracket can be connected either above or below the detector.


  • Configurable detection mode – allows configuration of UV-IR, UV or IR detection mode.



  • HART 7 models available - Easy configuration and diagnostic capability.


  • SIL 2 compliant models available - suitable for use as part of a SIL 2 compliant safety system.



 FlameSpec-UVIR–HD and UVIR-F-HD only:

  • HD video output with Automatic HD video recording of fire events.


  • Ethernet communication – in addition to the standard methods, such as Relays, 4-20mA and Modbus.




SPECIFICATIONS FlameSpec UVIR and UVIRHD:

Detection time and distance:

<5ms for fast burst of explosion

1.5s for 1 ft2 (0 .1m2) pan fire at 0 –50 f t. (0–15m)

<3s for 1 ft2 (0 .1m2) pan fire at 5 0–100 f t.(15–30m)

Field of View: 90° Horizontal, 75° Vertical

Time Delay: 0-30 seconds

Built in Test: Automatic and Manual

Operating Voltage: 24 VDC nominal (18-32 VDC)

Current Consumption: Standby: 120mA, Operation: 180mA all systems in operation (including window heater)

Electrical Entries: 2x conduit entries 3/4" 14NPT or M25x1.5 Wiring 12-20 AWG (2.5–0.35mm2)

Relays:  SPST volt-free contacts rated 2A at 30 VDC 3 relays: Alarm & Auxiliary – normally open; Fault – normally closed

Analogue Output: 0-20mA (stepped) current output 3wire and 4wire (isolated) configurations (sinkand source), with HART overlay.

Local Indication: Tri-colour LED

Size: 140x90x90mm

Weight: Detector (StainlessSteel 316):3.0kg Tilt mount (Stainless Steel 316):1.5kg

Temperature Range: Operating: -55°C to +85°C Storage: -55°C to +85°C

Humidity: Up to 99% (RH), non-condensing

Ingress Protection: IP66 & 68 (2m, 24hr); NEMA 4X & 6P

Explosion proof:

ATEX: I I 2 G D Ex db IIC T5 G b or Ex db eb IIC T5 Gb and Ex tb IIIC T95°C Db -55°C<Ta<75°C Ex db IIC T4 Gb or Ex db eb IIC T4 Gb and Ex tb IIIC T105°C Db -55°C<Ta<85°C

IECEx ExdbIICT5Gb-50°C≤Ta≤75°CExdbIICT4Gb-50°C≤Ta≤85°C

FM & FMC Class I, Div. 1, Groups B, C & D; T4 Class I, Zone 1, AEx/Ex db IIC T4 Gb T4-50°C≤Ta≤85°CT5-50°C≤Ta≤75°C

PerformanceApproval:  ANSI FM 3260 EN 54 -10

Functional safety: SIL2, per I EC 61508


SPECIFICATIONS FlameSpec UVIRHD only:

Current Consumption: Standby: 180mA, Operation: 250mA all systems in operation (including window heater)

Size: 200x130x130mm

Weight: Detector (StainlessSteel316):4.4kg Tilt mount (Stainless Steel316):2.4kg

HD Video: Allows clear imaging of fire and people at 100 ft. (30m) distance

Video recording: Alarm events 1-minute pre-event and up to 3 minutes post-event

System integration protocol: ONVIF (Open Network Video Interface Forum) Profile S

Digital Output (for video): IP network IEEE 802.3 10Base-t

Composite video output: NTSC or PAL

UVIR Flame Detector, UVIR Flame Detector with Video

UVIR Flame Detector, UVIR Flame Detector with Video

Downloads

 Click on the links below to download the Datasheets of the FLS UVIR Flame Detector Range ,

 go to our Resources page for application and selection information.

FLS-UV-IR-07 (pdf)

Download

FLS-UV-IR-HD-07 (pdf)

Download

FLS-UV-IR-F-06 (pdf)

Download

FLS-UV-IR-F-HD-06 (pdf)

Download

FLS-FSIM-03 (pdf)

Download

Video

Performance Benefits of the FGD FlamSpec Product Range

 Information on the perfomance gains FGD has made, and how they benefit the end user of the range of High Performance Flame Detectors

Detection in 4msec

FGD Flame Spec UV IR Flame Detector Utilised to Detect a Fire Explosion in  4ms.

FGD Flame Spec UVIR Range

Overview of the FGD UVIR Flame Detector Range
